Sub-surface

Installed from the underside of a desk or table, the Aircharge Wireless Sub-Surface Charger becomes an integral part of the furniture, maintaining the look & feel of the surface completely intact.

Logo etching guidelines for optimal device positioning must be followed.

Available with data connectivity for system monitoring, analytics & over-the-air updates.



Features

  • Fits any desk thicknesses – a 80mm ⌀ housing will be drilled from the underside of the table leaving maximum 4mm for optimal efficiency
  • Qi-Certified - supports all Qi compatible devices and Aircharge accessories
  • Safety protections - Foreign Object Detection, Overcharge protection, Temperature Sensor Control
  • Can be secured to underside of work surface using steel plate and screws provided
  • USB power cable allows multiple units to be connected to a hub (supplied separately)
  • Data connectivity supported

Technical Specifications

  • Input: DC 5V, 1500mA (plug must be this specification)
  • Power cable: 2m USB
  • Frequency: 100-200kHz
  • Certification: Qi-Certified
